Number: 4018 |
|
| |
| Category: |
Stack delivery |
|
| Manufacturer: |
palamides |
| Model: |
alpha 800 |
| Number: |
200... |
| Status: |
In production |
| Test: |
By prior appointment agreement possible |
| Location: |
Germany |
| Availability: |
Aug. 2026 |
| | |
| Machine: | stack delivery Palamides |
| Manufacturer: | - Palamides |
| Model: | - alpha 800 |
| Format: | Infeed Length x Infeed Width |
| - Minimum Format 90 mm x 90 mm |
| - Max. at 1-up 300 mm x 800 mm |
| - Max. at 2-up 300 mm x 380 mm |
| - Max. at 3-up 300 mm x 240 mm |
| - Max. at 4-up 300 mm x 170 mm |
| - Max. at 5-up 300 mm x 130 mm |
| - Max. at 6-up 300 mm x 105 mm |
| Stack height: | - Min. Stack Height: 20 mm |
| - Max. Stack Height: 120 mm |
| Stack level: | • For clean stack formation of saddle-stitched brochures |
| and 4-page folded brochures |
| Size control: | Electronic Format Monitoring with |
| - Electronic size monitoring with a waste-sheet diverter |
| • Misfolded products are ejected (tolerance: ±2 mm) |
| Equipment: | - Electronic Sheet Counter |
| - Pressing Unit |
| - Jogging Device |
| - Air Blast Device: |
| - Anti-Static Device |
| - Inspection Sheet Diverter |
| - Delivery table |
| Link: | - Saddle Stitcher Interface |
| • For operation on saddle stitchers |
| Navigator: | • For operation on MBO folding machines with Navigator control |
| Connection: | - Interface to machines from other manufacturers upon request by palamides |
| |
| Condition: | How it stands and goes |
| Speed: | Speed: 700 stacks per hour per up |
| Power supply: | This Machine Is Configured for 400 V, 50 Hz |
| Compressed air supply: | Compressed Air Consumption: 100 l/min net, 6 bar (without Air Blow Device) |
| Power input: | Electrical Connection: 3.5 kW |
| Important: | Observe Your Utility Company's Connection Requirements! |
| CE mark: | The machine bears the CE mark |
| Specifications: | Technical data and illustrations are subject to change. |
| |
| Price: |
On request |
| (exclude VAT) |
