Number: 4024 |
|
| |
| Category: |
1-color letterpress printing presses |
|
| Manufacturer: |
Heidelberg |
| Model: |
OHT |
| Built: |
1970 |
| Number: |
175... |
| Size: |
26 x 38 cm |
| Status: |
In production |
| Test: |
Available by prior appointment |
| Location: |
Germany |
| Availability: |
Immediate |
| | |
| Machine: | 1-color letterpress printing presses |
| Manufacturer: | - Heidelberger Druckmaschinen AG |
| Model: | - OHT |
| Feeder: | - Single-Sheet Feeder |
| Format: | - Max. Sheet Size = 260x 380 mm |
| Inking Unit: | - available |
| Application: | - die-cutting, creasing and perforating |
| |
| Condition: | How it stands and goes |
| Speed: | max. 5.500 sheets/h |
| Length: | 1.680 mm |
| Width: | 1.240 mm |
| Height: | 1.850 mm |
| Feeder: | 32 cm max. stack height |
| Delivery: | 32 cm max. stack height |
| Weight: | 1.100 kg total weight with 2 stacks |
| Air supply: | Pressure vacuum pump |
| Power supply: | This Machine Is Configured for 380 V, 50 Hz |
| Power input: | 1,3 KW/h |
| Safety: | Safety Devices |
| Important: | Observe Your Utility Company's Connection Requirements! |
| CE mark: | The Machine Does Not Bear a CE Mark |
| Specifications: | Technical data and illustrations are subject to change. |
| |
| Price: |
On request |
| (exclude VAT) |
